5dB ST/PC Yin-Yang Optical Attenuator 10pcs ST Single Mode Fiber Attenuator

5dB ST/PC Yin-Yang Optical Attenuator 10pcs ST Single Mode Fiber Attenuator The Yin-Yang Type Fiber Optic Fixed Attenuator is a type of connector that has one end as an adapter and the other end as a connector. The attenuation value is adjustable. This range of fixed attenuator is mainly used to reduce optical power to a target value in optical links. [Features] 1. Good interchangeability and repeatability 2. Accurate attenuation 3. High reliability 4. Compliant with the IEC and RoHS standards 5. Conforming to Telcordia-GR-910-CORE [Applications] 1. Testing instruments 2. Connection between devices 3. Connection between fiber optic patch cords 4. CATV, MANs, WANs 5. FTTx [Specification] Parameter Typical Vlue Unit Single Mode Testing Wavelength 1310,1550 nm Operating Bandwidth Range 1,250~1,650 nm Retiurn Loss ≥60.0 dB Attenuation Range 0~30 dB Attenuation Tolerance 0~5,±0.5 dB 5~30dB,±10% / Repeatability ≤0.10≥ dB Exchangeability ≤0.20 dB Durability 1,000 Mating, loss≤0.20 dB Maximum Input Power ≤200 mW Operating Temperature -2 0~ 70 ℃ Storage Temperature -40 ~ 85 ℃   [Package Include] 10pcs Yin-yang optical attenuator SKU: P779 Category: Yin and Yang Type Fixed Attenuator Tag: optical attenuator
