520nm 1~40mW Adjustable Output Power Green Laser PM Fiber Output

520nm 1~40mW Adjustable Output Power Green Laser PM Fiber Output [Features] Fiber is pluggable M²≤1.2 Polarization ratio>70:1 TEC temperature control, air cooling [Applications] Fluorescence spectroscopy, photodetection, optical measurement, etc. Note: Lead Time: About 2~4 weeks. [Specification] Parameter*1 Working Conditions Symbol Min. Value Typical Value Max. Value Unit Optical Parameters Output Power(CW) @PO PO 40 mW Power Stability (RMS) 2hrs Ps 3 % Central Wavelength @PO λc 515 520 525 nm Spectral Linewidth (FWHM) @PO Δλ 1 2 nm Preheat Time @PO Tw 5 min Noise RMS(10Hz-100MHz) N 1 % Polarization Ratio @PO 70:1 Optical Fiber Parameter Index*² Fiber Specifications PM Fiber Fiber Length L 1.0 m Fiber Numerical Aperture NA 0.12 Fiber Interface FC-PC/FC-APC Electrical Parameter Index Operating Voltage @PO Vin 90 220 245 V TTL Modulating Frequency 100 KHz Electrical Parameter Index Service Life*³ @PO/room temperature MTTF 10,000 Hrs Operating Temperature Tstg 0 40 ℃ Storage Temperature Topr -20 65 ℃ Note *1: Test data at 25°C operating temperature; *²: Fiber length and fiber interface can be customized; *³: The service life refers to the service life of the laser diode.   SKU: P629 Category: 520nm PM Fiber Coupled Laser Tags: 520nm laser, fiber output
